| WOP-3120T-C4AE |
| Communications |
COM1 |
RS-232/RS-422/RS-485 (DB9) |
| I/Os |
USB 2.0 Client x 1, USB 2.0 Host x 1 (Top), Micro-SD Slot, Audio 1 Line-out / 1 Mic-in |
| General |
Certifications |
BSMI, CCC, CE, FCC Class A, UL |
| Dimensions |
311 x 237 x 46.8 mm (12.24" x 9.33" x 1.84") |
| Cut-out Dimensions |
302.5 x 228.5 mm (12.1" x 9.14") |
| OS Support |
Microsoft® Windows WES7 32bit/64bit /WE8S 64bit /Windows 7 32bit/64bit / Windows 8 64 bit / Linux Kernel |
| Power Input |
24VDC ±10% |
| Power Consumption |
12 W |
| Enclosure Housing |
PC + ABS |
| Mounting |
Panel |
| Weight (Net) |
2.5 kg (5.51 lbs) |
| System Hardware |
CPU |
RISC 32 bits, 600 MHz (ARM® Cortex™-A8) |
| Battery Backup Memory |
FRAM 1M bit (=128K Byte, 64word |
| Flash Memory |
DDR2 256MB on board |
| Storage |
512MB on board SLC type |
| Power-On LED |
Yes |
| Communications |
COM2 |
RS-422/RS-485 (Terminal 4pin+Ground) |
| COM3 |
RS-485 (Terminal Plug 2-Pin) |
| CAN |
Terminal Plug 2-Pin |
| Ethernet |
10/100-BaseT |
| LCD Display |
Display Type |
XGA TFT LED LCD |
| Display |
Size |
12" |
| LCD Display |
Max. Resolution |
1024 x 768 |
| Max. Colors |
64K |
| Luminance (cd/m2) |
500 |
| Backlight Life |
LED, 50,000 |
| Viewing Angle (H/V°) |
160/140 |
| Dimming |
Adjustable by touch panel |
| Contrast Ratio |
500:01:00 |
| Touchscreen |
Lifespan |
36 million touches at 8mm-diameter finger poin through silicone rubber bearing at least 250g 2 times per second. |
| Light Transmission |
Transmission Above 80% |
| Resolution |
Linearity |
| Touch Type |
5-wire, analog resistive |
| Environment |
Temperature (Operating) |
-20 ~ 60°C (-4 ~ 140°F) |
| Temperature (Storage) |
-30 ~ 70° C (-22 ~ 158° F) |
| Humidity (Operating) |
10 ~ 90% RH @ 40°C, non-condensing |
| Ingress Protection |
Front panel: IP66 |
| Vibration Protection |
Operating, radom vibration 1 Grms (5 ~ 500 Hz) |
